- 12HP Eurorack Module, requires compatible Eurorack case/power supply
- Ping (tap tempo) button for manually setting the tempo
- Ping jack sets tempo via external clock (any complex signal may be used as a clock)
- Latching On/mute button enables or mutes output (lights up when channel is on)
- Skew knob and CV jack control the waveshape by adjusting the ratio between rise and fall times
- Reset jack restarts the LFO without changing the tempo (rising edge triggered)
- Out jack outputs either a 0 to 10V waveshape, or a -5V to +5V waveshape (jumper selectable)
- LED flashes and dims to the signal at the Out jack
- Ping button flashes to internal tap-tempo clock or to incoming pulses on the Ping jack
More Info: Quad Pingable LFO
