The X-TOP series is a “heavy duty” XLR cable connector for outdoor use. Outdoor protected by mating with related cable or chassis connector of the XLR TOP range (IP65 and UL50E). Gold contacts are standard.
| Product type | Plugs and Connectors |
| Type | XLR |
| Poles | 3 |
| Gender | male |
| Color | Black |
| Contacts | brass |
| Connection type | solder contacts |
| Capacitance between contacts | 4 pF |
| Resistance | 3 m Ohm(s) |
| insulating resistance | > 10 G Ohm(s) |
| Rated Voltage | < 50 V |
| Rated current per contact | 16 A |
| Housing | Steel |
| Cable O.D. | 5 – 8 mm |
| Wiresize | max. 1.5 mm² |
| Wiresize (AWG) | max. 16 AWG |
| Latch | Latch lock |
| Certificates | UL |
| Fire protection class | UL 94 HB |
| Protection class IP | IP65 |
| Temperature range | – 30 °C / + 80 °C °C |
| Weight | 0,0335 kg |
