The Quintet Blue’s sound image will tend to more smooth reproduction compared to Quintet Red and moderate dynamic strength compared to Quintet Bronze.
It features a Nude Elliptical diamond mounted on an aluminium cantilever. The Quintet Blue will bring more space, depth and detail into the sound and is a very good choice for any kind of music, especially rhythmic.
Specifications
- Channel balance at 1 kHz: < 1.5 dB
- Output voltage at 1 kHz, 5cm/sec: 0.5 mV
- Channel separation at 1 kHz: > 21 dB
- Frequency response 20 Hz – 20 kHz: +/- 2.5 dB
- Tracking ability at 315 Hz: 70 µm
- Compliance, dynamic, lateral: 15 µm/mN
- Stylus type: Nude Elliptical
- Stylus tip radius: r/R 8/18 µm
- Tracking force range: 2.1-2.5 g
- Tracking force, recommended: 2.3 g
- Tracking angle: 20°
- Internal impedance, DC resistance: 7 Ohm
- Recommended load impedance: > 20 Ohm
- Coil wire material: Pure 4-nines silver
- Cartridge body material: PC
- Cartridge colour: Blue
- Cartridge weight: 9 g
For more information please visit the manufacturer’s website
