In collaboration with ANDREW HUANG, based on his modern music production techniques, we developed a creative audio processor with multiple blocks that can be moved around in order to achieve different flavors for sound design

• audio processing unit without fixed structure: intuitively create astonishing and ephemeral timbres: from atmospheric rumbles to heavy or distorted textures

• creative stereo effect processor with delay, reverb, filter and distortion with quickly explorable routing chain with single button press

• new generation ARM Cortex - M7 processor with 96 kHz 32 bit internal processing

• lush hall with shimmer and freeze and whooshing reverse reverbs with tone control and pre-delay

• sidechain audio ducking with trigger input and one knob single band compressor

• zero-delay feedback state-variable filters: bipolar low-pass / high-pass, band-pass and alternative comb filter with resonator

• tap delay with external clock and clock divider, 1v/oct time control for Karplus-Strong, looper, tone control, various taps settings with up to 2,5 sec. maximum delay time

• 8x oversampled distortion algorithm

• pre- and post- VCA controls, input Tone and output Volume/Mix controls with extra gain/drive reserve

Power consumption

• 135 mA +12V

• 35 mA -12V

• 0 mA 5V

Dimensions

• 16 HP

• 25 mm / 1″ deep with power ribbon cable connected

More information you can find here: Ghost Audio Processor
