Bass frequencies from 32 Hz to 250 Hz are handled by ADAM Audio’s entirely new 9-inch Extended Linear Excursion (ELE) LF driver, which incorporates the company’s equally groundbreaking Symmetrical Magnet Assembly (SMA) and delivers a powerful, extremely accurate low end extending right down into the sub-bass region. Mid-range and HF information is reproduced with equally analytical precision thanks to the combination of ADAM Audio’s newly developed 4-inch DCH mid-range driver and the highly refined S-ART folded-ribbon HF driver. Together with the brand-new HPS waveguide, the latter offers high-frequency reproduction with an extremely broad sweet spot with fine, highly detailed imaging and a natural-sounding sense of depth.

The S Series’ custom-designed DSP optimizes the loudspeaker crossovers to create linear responses for the entire range, as well as providing user equalization and in-room tuning/voicing functions. The DSP also handles the limiter-based high-frequency driver protection, processes the signals from the AES3 digital inputs, and will in time facilitate various expansion options. Software updates can be carried out with ease via the associated USB port, which also allows users to connect computers and control the speakers’ DSP functions via a software front-end.

The S3V’s built-in amplification is generously specified, comprising Class D units for the bass and mid-range drivers (500 W and 300W RMS respectively) and a 50 W Class A/B amplifier for the S-ART tweeter.

Offering flawless reproduction of audio frequencies between 32 Hz and 50 kHz, the S3V is a standout offering for anyone demanding highly accurate imaging and localization from their reference monitors.

Active 3-Way Midfield Monitor

• 9" woofer
• 4" Midrange
• 2" S-ART tweeter with HPS Waveguide
• Amplifier power: 500 watts woofer, 300 watts midrange, tweeter 50 watts
• Frequency range: 32 to 50,000 Hz
• Maximum level: 124 dB (pair 1 m)
• Built-in DSP processor
• Adjustable input sensitivity
• Room correction (Parametric EQ, High-Shelf EQ, Low-Shelf EQ, Preset Memory)
• Analogue input XLR
• AES3 digital input and output
• USB port for software upgrades and computerised operation
• Built-in switched-mode power supply 100-240 V
• Dimensions (H x W x D): 536 x 293 x 380 mm
• Weight: 25 kg
• Price per unit
