24-Track Flagship Analog Recording Console & Live Mixer with Audio Interface
22 channels, 24 tracks, one solution - from performance to recording, Model 2400 re-defines what you can do with a studio recording and live mixing console.

Key Features

• 24-track multitrack recorder using SDXC SD card (punch-in/out supported)
• 24 in / 22 out USB audio interface
• 22 analog input channel modules with 16 XLR Mic Pre-amps, utilizing TASCAM ultra HDDA Mic Pre-amp technologies and a one knob compressor (Ch 1-12)
• Equipped with input inserts (SEND/RETURN) on channels 1 - 12
• 5 Aux (4 Aux plus internal FX) sends, 4 stereo sub group and Main L/R
• MIDI in/out allows USB MIDI interface and MIDI sync, 1/4" audio click output with tempo control
• DAW transport control and REC READY control via HUI/MCU
• Dedicated Settings Panel application with Meter bridge

Other Features

• Selectable send Pre/Post EQ routing for Recording
• Ch compressor and EQ bypass function available for MTR and USB return
• Phantom Power (+48V) selectable ingroups of 4 channels
• 100Hz Low-cut Filter (Ch 1-12)
• 3 Band EQ (Ch 1-12: sweep-able mid-range frequency)
• Dedicated 100mm fader (Ch 1-22, stereo Sub1-4 and MAIN L/R)
• Internal 4 band EQ and master compressor on Main bus
• Equipped with inserts (SEND/RETURN) on Main bus
• PFL/AFL function with LED indication in all input / output modules
• MAIN outputs L/R via XLR balanced; TRS ¼" outputs via Sub 1-8, Aux 1-5 and Control Room output
• 2 Phone outputs
• Talkback XLR microphone input
• 16 TASCAM on-board studio quality Effects such as reverb, delay, chorus with fader control
• Bluetooth® input supporting both AAC and SBC codecs

More info: Model 2400
