Yamaha AG06 MK2 (Black)
Yamaha AG06 MK2 (Black)
Pieejams pasūtīšanai
Apraksts / Specifikācija
Apraksts / Specifikācija
The white AG06MK2 from Yamaha is a compact 6-channel mixer and USB interface with built-in DSP for streaming, sound reinforcement, and recording small performances, podcasts, lectures, and similar applications. This updated MK2 version adds a mute button and 3.5mm TRRS input for more flexible live streaming work. It also features an improved build design with updated circuitry for better sound. Capable of recording and playback of high-resolution 24-bit / 192 kHz sound, this mixer features two XLR-1/4″ combo mic/line inputs, as well as a stereo 1/4″ line input pair, a stereo RCA input pair, and a 3.5mm aux input for portable music players and headsets. The mixer is compatible with Windows/Mac computers as well as iPads and iPhones.
The XLR-1/4″ combo mic/line inputs feature switchable 48V phantom power for use with condenser microphones, and input 2 offers a Hi-Z switch for use with electric guitar and bass. The AG06MK2 mixer has stereo 1/4″ and stereo RCA outs for connecting to your PA system or monitor speakers. It also has a 1/4″ headphone output with level control for personal monitoring.
- Two Mic/Line Combo Inputs
- Two 1/4″ Line Inputs, Two RCA Inputs
- 3.5mm TRRS In/Out for Smartphone
- Record & Playback up to 24-Bit / 192 kHz
- Zero-Latency DSP FX, Loopback Function
- 48V Phantom, Hi-Z Switch for Guitar
- 3.5mm TRS Input for Headset/AUX
- 1/4″ and RCA Stereo Outs
- Powered via USB
- Works With PC, Mac, iPhone, and iPad
| Audio interface | Yes |
| Channels | 6 |
| Ieejas | 6 |
| Inputs – Mic Preamps | 2 |
| Phantom Power | +48 V |
| Inputs – Line | 4 |
| Izejas | 4 |
| Outputs – Main | 2 x 1/4″ TS Unbalanced Mono Monitor/Record Output (1 Stereo Pair) |
| Outputs – Other | 2 x RCA, 1 x 1/4″ TRS, 1 x 1/8″ / 3.5 mm TRRS, 1 x 1/8″ / 3.5 mm TRS |
| Built In FX | Nē |
| USB | 1 x USB Type-C (USB 2.0, 2-Track Record, Audio Playback, Audio Streaming, Control, Host Connection) |
| Izmēri | 20.1 x 15.2 x 6.3 cm |
| Svars | 900 g |
