Dual balanced inputs and outputs for the studio or on the go. Connect your rack to the balanced line-level world; send and return signals to pedals or desktop effects units; patch in and out of your DAW, external synths, drum machines, and other line-level instruments.
Get Connected
Audio I/O (2023 edition) lets you effectively connect your Eurorack modular system to the balanced line-level world (+4 dBu). You can send and return signals to rack-mount or desktop effects units, patch to external line-level instruments like synths and drum machines, interface with a DAW, and much more.
The 2023 edition moves the TRS jacks to the top of the panel.
The rear-mounted 3-pin CHAIN IN connector lets you sum (in parallel) other audio sources to convert from Eurorack level to the BAL LINE OUTPUTS. This could be from modules like the Mixup 3U, Xfade 1U, Stereo Mix 1U, and XY I/O 1U. You can also use this to connect with the 3-pin headers on the Palette and 7U cases audio I/O boards.
The rear-mounted 3-pin CHAIN OUT connector lets you directly connect the level-shifted BAL LINE IN to the inputs of other compatible devices such as the Mixup 3U, Outs 3U, Stereo Mix 1U, XY IO 1U, and Headphones v2 1U. You can also connect it to the TRS jacks of the Palette and 7U cases audio I/O boards.
Features
2 x balanced TRS 1/4″ to Eurorack modular level input paths
2 x Eurorack modular level signals to balanced TRS 1/4″ output paths
4 x six-stage analog LED VU meters to monitor all inputs and outputs simultaneously
Input path has up to 20 dB of gain, allowing you to patch in low-level consumer signals and boost them
Output path steps a nominal Eurorack level (10 Vpp) down to +4 dBu with up to +6 dB gain
3-pin CHAIN IN connector
3-pin CHAIN OUT connector
